Rapcon Pmax

XC Race/Marathon
0 from 6
Tour
6 from 6
Allmountain
6 from 6
Enduro
6 from 6
Watch out for this powerhouse! The Rapcon Pmax by Simplon is a lightweight and incredibly versatile trail fully that merits an entirely new definition of the term “E-MTB”. You’re wondering: How so? With up to 1,125 Wh of battery capacity, you’ll be “collecting” summits one after another. What gives you the power for that is the latest Bosch CX drive unit, embedded in the high-quality carbon frame. Downhill, the Rapcon Pmax impresses with strong-grip 29’’ tyres, a well-conceived geometry as well as an exceptionally plush suspension setup. Unlike any other bike, the E-MTB playfully manoeuvres you through even the most challenging of trails.

Details

Who’s the E-MTB fully perfect for? Which special features does the Rapcon Pmax have? And what sets it apart from the competition? Let’s find out … Risky rock passages, slippery hidden roots and hanging curves are your speciality? Then the mountains are calling – and the Rapcon Pmax is definitely the right way to answer! The trail and all-mountain e-mountain bike plays to its strengths both on challenging downhill passages and on steep uphill climbs. With up to 1,125 Wh under its saddle, climbing multiple summits becomes a piece of cake. If you’re into wild rides on the trails, you’ll hardly get past the Rapcon Pmax. Which other exceptional USPs does the e-fully have to offer? Read more!

Features

  • The beautifully designed carbon frame ensures low weight at optimum stiffness, and also impresses with a modern look.
  • Special highlight: The dual-battery option with integrated 625-Wh battery and external 500-Wh battery in and on the down tube. With 1,125 Wh, you’re guaranteed nearly inexhaustible support even on long tours. Convenient: In case you don’t need the second battery, you can install a bottle cage via the mount instead.
  • The Performance Line CX drive unit by Bosch is a true powerhouse among drive units – and of course, was built-in on the Rapcon Pmax. Even on challenging tours, it gives you even more riding fun with a torque of up to 75 Nm – at a weight of 2.9 kg and a particularly compact frame size.
  • More agility and grip during climbs as well as better handling in curves: That’s possible thanks to mixed wheels with 29’’ in the front and 27.5’’ in the rear. The stylish Rapcon Pmax optionally rolls on 29’’ tyres too – thanks to its wide tyre clearance. By the way: Via flip-chip, the geometry can be easily adapted to individual needs.
  • The E-MTB also has extensive frame protection: stainless steel protectors on the rear bearing points, the unscrewable cable routing on the left seat stay and the battery cover made of cushioning rubber on the bottom of the down tube.
  • The ventilation slots in the steering head let cool air enter on downhill passages and warm air exit on uphill climbs. This prevents the battery from overheating. Additionally, the cables can alternatively be routed through the ventilation slots.

Technology

Air conditioning via the ventilation slots on the steerer head. Stainless steel protectors – Linkage Shield – that protect the carbon frame from getting scratched. The pivoting cable guide, also called Center Cable Guide in Simplon jargon, not only neatly “cleans up” the look of the bike but also sets new standards in cable routing. These fine-tuned technology features are included in the Rapcon Pmax E-MTB. You want even more? Well, here you go:

Options

Simplon offers numerous optional features for the Rapcon Pmax – for ultimate riding fun on the trails, uphill as well as downhill. Promise! Have you ever heard of an e-suspension? Not yet? Then it’s about time! With Live Valve for the Performance Line CX drive unit, FOX offers an electronically controllable suspension setup for the first time. Via elaborate sensor technology in the front and in the rear, the particularities of the terrain are detected – 1,000 times per second – and the fork and shocks are adjusted within seconds. Unprecedented riding pleasure guaranteed! With the RockShox steel-spring shocks, the Rapcon Pmax checks all the boxes for the latest downhill-oriented trail bikes. The most important benefits: precisely adjustable pressure levels for all types of terrain and a noticeable suspension platform for maximum pedalling efficiency. And let’s not forget the modern RockShox Super Deluxe Design!


  • wheels
  • seat post
  • ergonomic cockpit
  • braking systems
  • lighting system
  • fork models
  • Bordcomputer
  • dual battery
  • Damper
  • crank box

Geometry table

Does the E-MTB fit your proportions and riding style? Which frame size do you need? The geometry table by Simplon helps you find the right mountain bike for your individual needs. Because there’s one thing you should know: The geometry is the deciding factor in how your bike acts on the trails.

Rapcon Pmax 150/150** S M L XL
A 390 420 450 480
B 571 592 625 658
C 66° 66° 66° 66°
D 76° 76° 76° 76°
E 90 95 110 125
F 460 460 460 460
G 1190 1212 1249 1285
H** 30/20 30/20 30/20 30/20
I 561 561 561 561
K 51 51 51 51
L 150 150 150 150
M 760 766 766 766
N 150 150 150 150
S 604 609 622 636
R 420 440 470 500
STR* 1,44 1,38 1,32 1,27
A Seat tube length mm
B Top tube length
C Head tube angle
D Seat tube angle
E Head tube length
F Chainstay length
G Wheelbase
H** Bottom bracket drop
I Fork length
K Fork offset (rake)
L Fork travel
M Stand over height
N Travel (Frame)
R Reach
S Stack
STR* Stack to Reach

*STR: The higher the number, the more upright is the seating position.

**Left BB Drop with 29“ front and rear with Flipchip low, right BB Drop when 29“ in front and 27,5“ in rear with flip chip high

Rapcon Pmax 170/160** S M L XL
A 390 420 450 480
B 572 594 627 660
C 65,1° 65,1° 65,1° 65,1°
D 75,1° 75,1° 75,1° 75,1°
E 90 95 110 125
F 458 458 458 458
G 1198 1220 1257 1293
H** 23/16 23/16 23/16 23/16
I 581 581 581 581
K 51 51 51 51
L 170 170 170 170
M 768 774 774 774
N 160 160 160 160
S 610 615 628 643
R 411 431 461 491
STR* 1,48 1,43 1,36 1,31
A Seat tube length mm
B Top tube length
C Head tube angle
D Seat tube angle
E Head tube length
F Chainstay length
G Wheelbase
H** Bottom bracket drop
I Fork length
K Fork offset (rake)
L Fork travel
M Stand over height
N Travel (Frame)
R Reach
S Stack
STR* Stack to Reach

*STR: The higher the number, the more upright is the seating position.

**Left BB Drop with 29“ front and rear with Flipchip low, right BB Drop when 29“ in front and 27,5“ in rear with flip chip high

Test Reports

Rapcon Pmax tested by E-MTB

Rico Haase, a tester for the E-MTB Magazine, rates the e-fully Rapcon Pmax by Simplon as “Full-Speed Tip” and “Editor’s Choice”. Read the test review!

Read more!

Under scrutiny by bikesport e-mtb | The Rapcon Pmax by Simplon

The testers of bikesport e-mtb all agree: The Rapcon Pmax is an impressive allrounder of an e-mountain bike. To the in-depth test review!

Read more!

Rapcon Pmax wins the Design & Innovation Award | Simplon E-MTB

Simplon scoops up the Design & Innovation Award (DI.A) 2020 for its e-mountain bike Rapcon Pmax. Find out more about the award and the winning E-MTB!

Read more!

First ride by Velomotion: Rapcon Pmax

The new Rapcon Pmax was put through a first check by Velomotion. What stood out was the bike’s variability, design and technical finesse. To the test review!

Read more!
"

Simplon Experience Center

At Simplon’s Experience Center in Hard, you get to experience the fascination with our bikes first hand

Rapcon Pmax the test

Take a look: the ultimate endurance test for the Rapcon Pmax - the new fully-equipped E-Fully performs so well.
