Grid :eLight

Graveling with a tailwind: The GRID :eLight with the TQ HPR60 Light Assist motor, a slim 290 Wh battery and 45 mm tyres is quiet, efficient and comfortable. With 12 mounting points, it’s ready for bikepacking, touring or commuting. For everyone who likes to go further than planned.

from

€ 4,999.00

from

CHF 4,999.00

Lightweight

Performance

Touring

Commuting

E-Power

Print

Prices in EUR

Prices in CHF

print technologies and options

print geometry table

Ask an expert

Find a Dealer

When the tarmac ends - and the adventure begins.

Frame material

Carbon

Total bike weight

from 12,69 kg

System weight (bike + load)

130 kg

Fork travel

40 mm (optional)

Motor

TQ-HPR60 | 60 NM | 200 W | 200 %

Battery

290 Wh | Range Ext: 160 WH (Optional)

Grid :eLight

Ask an expert

configure now

Find a Dealer

Ready for whatever lies ahead.

6 mounting points each on the frame and fork make your bike ready for any adventure - perfect for bikepacking.

So smooth, it’s almost not there.

The TQ-HPR60 kicks in exactly when needed – smooth, strong, and so natural you might forget it’s even there.

Hard to spot. Even harder to beat.

Thanks to seamless integration, the slim silhouette stays intact – the e-system blends so smoothly into the GRID :eLight that you'll have to look twice.

Fully there. Barely visible.

The integrated display shows the key info at a glance – discreetly built into the top tube and easy to read, no matter where the trail takes you

More clearance. More terrain.

Up to 50 mm of tire clearance makes the GRID :eLight ready for rougher terrain – and if you’re after extra comfort, an optional 40 mm suspension fork has you covered.

Small detail. Big impact.

The sleek remote sits ergonomically on the handlebar, is easy to use – and even supports you when pushing the bike.

Sealed. Smart.

The weatherproof charging port with spring-loaded cover is well protected against moisture – and still easy to open and close with just one hand.

Ride naturally. Go further.

With a 290 Wh battery and a light-assist motor, you get more range without losing that natural riding fun – perfect for long gravel days.

Comfort meets off-road

The Comfort Concept with Raptor Dropout and 45 mm Overland tires smooths out the rough stuff without losing grip – ideal for long gravel rides on challenging terrain.

Gravel, as smooth as it gets

In the morning on asphalt through the early fog, in the afternoon on gravel paths, past the forest edge and up into the first climbs. The GRID :eLight makes days like this possible. Developed for everyone who enjoys being outdoors – even when the route gets demanding. The TQ drive provides quiet, unobtrusive support when the going gets tough or the headwind just won’t let up – with up to 60 Nm of torque when you need that extra push. If you prefer, you can ride it without assistance, too. The carbon frame stays light, the handling direct – even with luggage or on loose ground. Comfort matters on long rides: wide tyres, smart geometry and a frame that noticeably smooths out rough surfaces. And if you're not done yet: plug in the range extender and keep going. The GRID :eLight is built for days when a short ride turns into a real adventure.

Geometry

The geometry table will help you find the perfect frame size.

Grid :e Light		45/XS	49/S	53/M	57/L	62/XL
A	Seat tube length	430	465	500	535	570
B	Top tube horizontal	535	550	570	585	605
C	Head tube angle	70°	70°	70°	70°	70°
D	Seat tube angle	74°	74°	74°	74°	74°
E	Head tube length	115	135	160	180	200
F	Chainstay length	430	430	430	435	435
G	Wheelbase	1025	1042	1063	1085	1106
H	Bottom bracket drop	75	75	75	75	75
I	Fork length	415	415	415	415	415
K	Fork offset	48	48	48	48	48
M	Standover	725	762	788	818	847
R	Reach	375	385	398	408	422
S	Stack	557	575	599	618	636
STR *	Stack to Reach	1,48	1,49	1,5	1,51	1,51
R+	Reach+
S+	Stack+
STR+	Stack to Reach+
		-12°	-12°	-12°	-12°	-12°
		70	70	80	80	80

All lengths in mm
* STR: Higher number indicates more upright sitting posture

Ask an expert

Facts & Figures

Technical details

MAX. weight (bike + rider + GEar)	130 kg
FORK TRAVEL / LENGTH / OFFSET	0 / 415 / 48 mm
AXLE STANDARD FRAME	142 x 12 mm
THRU-AXLE	172 x M12 x 1.0 mm
Fork installation dimensions	100 x 12 mm
MAX. tire dimension	ETRTO: 45-622 (without mudguard) / Inch: 28 x 1.70
MAX. brake rotor size	180 mm
brake mount	FM160
seat tube diameter	27,2 mm
headset standard	ZS56 / ZS56
Headset	ACROS AZA636
MAX. chainring size	44 T
DERAILLEUR HANGER	UDH
water bottle mounts	2
Motor	TQ-HPR60
Max. Support Level	200 %
Max. Torque	60 Nm
Max. Power	250 Watt
Battery Capacity	290 Wh
Range Extender	160 Wh
Charge on Bike	Yes
Removable Battery	Only in service
Child Trailer Readiness	No
Kickstand Compatible	KSA18
	The illustration above is an example. We reserve the right, provided that the type, suitability and purpose of the bicycle are not impaired, to replace individual parts with components of equal or higher value so that the bicycle is delivered differently.

Intended use

Bike classification: ASTM category 2
Learn more (PDF)

Bicycles and e-bikes that are used on unpaved roads, gravel roads, forest roads and light trails (S0) with moderate ascents and descents in addition to category 1 use. Under such conditions, contact with bumpy terrain and repeated loss of tire contact with the ground may occur. Jumps and drops are limited to 15 cm or less.
Jumps & drops: ≤ 15 cm
Skills: moderate riding technique required
Bike type: Trekking Bike, Gravel Bike
